Adopting an integrated casting process, the flow channel is designed as a straight through or angular type, and the inner wall is precision polished to be smooth without dead corners, reducing the flow resistance of the medium; Both flange connection and clamp connection interfaces can be customized to meet different pipeline installation requirements.

• Smooth opening and closing, good resistance to water hammer: The rotary motion trajectory of the valve disc is smooth, with no impact when opened. When closed, it slowly resets with the help of the reverse pressure of the medium. Paired with a balance hammer or damping device, it can further slow down the closing speed, effectively weaken the water hammer effect.
• Strong circulation capacity and minimal pressure loss: The straight through flow channel design reduces turbulent losses in medium flow. When the valve disc is fully opened, it is parallel to the axis of the flow channel and produces almost no additional resistance. It is particularly suitable for conveying large-diameter and high velocity media.
• Reliable sealing, suitable for multiple media: The metal hard seal and soft seal can be flexibly switched. Metal seals withstand high temperature, high pressure, and erosion; Soft sealing achieves zero leakage under low pressure, suitable for water, steam, oil, and chemical raw materials.

This valve sees extensive utilization in pipeline networks spanning diverse industries, ranging from chemical manufacturing, petroleum refining and marine engineering to pharmaceuticals, food and beverage production, power generation and water treatment. It demonstrates exceptional suitability for corrosive substances, high-temperature and high-pressure media, and high-purity fluid systems.

Standard export wooden case packaging ensures the integrity of the valve during international shipping and handling.
